ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
คุณสมบัติหลัก
Stainless steel structure;Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
การตอบสนองต่อน้ำหนักและสัดส่วนของแทร็กช่วยลดปัญหาการขาดแคลนของน้ำหนักบรรจุที่ผันแปรตามสัดส่วนของวัสดุที่แตกต่างกันได้
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Datก
Hopper | Quick disconnecting hopper 25L |
น้ำหนักบรรจุ | 10 - 1000g |
ความถูกต้องบรรจุ | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
ความเร็วในการบรรจุ | 5 – 20 times per min |
แหล่งจ่ายไฟ | 3P AC208-415V 50/60Hz |
กำลังไฟทั้งหมด | 2.25Kw |
น้ำหนักรวม | 350kg |
Overall Dimensions | 1205×1010×2174mm |
